Installation Notes:

(1) Do not use this product falls on the ground or by strong percussion;
(2) unless instructed otherwise, do not dismantle the machine;
(3) before use to determine whether the specified power supply voltage;
(4) to avoid targeting light (such as sunlight, lighting, etc.), otherwise easily lead to too bright or pull light phenomena (this is not a failure), will also affect the CCD life;
(5) Avoid wet conditions, dust, extreme heat, extreme cold, strong electromagnetic radiation and other venues;
(Not include OSD Menu and Power Supply ,Suggest Camera Don't use completely dark environment)

important Notes:

1>>This is Full HD AHD 1920P Camera ,Work Must use 1080P Recording Format AHD DVR (AHD-H System or AHDN-1080N System)!! If NO USE 1080P Record AHD DVR, AHD Camera NOT Work .

2>>You Can't use AHD-M SYSTEM 720P Record AHD DVR and Common DVR ,the AHD Camera it NOT Work!!!

3>>Camera Work Can only use 1080P Record AHD DVR!!!

4>>We have high quality AHD DVR which can be purchased from our store if needed.

How AHD can be beneficial to us?

• Upgraded to analog HD seamlessly with Low-cost and simple installation value-added solution. Go after the conventional analog system topology and give a full consideration to users’ operation habit.

• Megapixel & uncompressed image quality.

• Long range & non-latency reliable video transmission without additions of relay devices.

• Strong anti-interference capability & solid interface protection. Free of high-frequent electromagnetic radiation; constant signal transmission and display without problems as frame drop and lock loss occurred.

• An open analog HD transmission system established and evolved industry chain developed to sustainably improve the technical standard.

What is AHD?

AHD (Analog High Definition) is a newly developed solution for transmitting full HD digital video in a surveillance system. The core concept of AHD is to deliver high definition video using digital TV (DTV) transmission. With AHD, high definition digital video can be transmitted easily over coaxial cables, twisted pairs, or simply over the air. Multiple 1080p30 and 1080p60 video streams can be easily transmitted using AHD over a single 5C2V/RG6 cable up to a length of 1000 meters without any repeater ( Up to 500 meters in case of 3C2V/RG59 ).



In the world of analog TV, The composite video baseband signal (CVBS) is the most commonly used signal format. Its popularity, ease of use, and robustness have made it an integral part of our lives. CVBS is in fact a de facto signal standard for analog video surveillance systems. As we bid farewell to analog TV with worldwide analog switch-off (ASO) and move on to the age of digital TV, digital technologies, such as DVB-T, ISDB-T, and ATSC, became popular and indispensable much like CVBS in the analog age. AHD leverages the extremely robust AV transmission capability of DTV to easily and seamlessly upgrade an analog cctv surveillance system to digital full HD. It is expected AHD to become a de facto standard for digital video surveillance systems in the future.

Why AHD?

As the industry moves from standard definition to high definition, how can we ensure the whole surveillance system not only satisfies the resolution requirement, but also the total cost?

Super Video Technology presents Analog High Definition(AHD) technology to the market. AHD is an over-coaxial-cable analog HD video transmission standard, allowing long-distance HD transmission at a lower cost to meet the requirements for a complex and large installation.

Specification:

Main Chip
High performance

Sony processor

Image Sensor
1080P:1/3 Sony IMX323+NVP2441H

3MP:1/3 Sony IMX291+FH8536E ( Starlight )

Effective Pixel
PAL : 1920*1080@25fps

NTSC : 1920*1080@30fps

Signal System PAL/NTSC
Video Standard Follow AHD and CVBS Standard
Video Output 1CH AHD HD/CVBS Standard Singal Output(Switchable)
Max Transmission Distance Common 75-3 Cable can be up to 500m
HD 3MP Lens size 3.6MM
Minimum Illumination 0.0001LUX/F1.2(Led on)
3D Noise Reduction YES
LED NO
Lightning protection YES
Shutter Speed 4/25s-1/45,000s
BLC Off/Low/Medium/High/Highest
White Balance Auto White Balance
HLC Auto
Operation Temperature -45°C~55°C
Power Supply DC12V
Housing Material Metal
IP Grade IP65 indoor
