ASECAM 3MP AHD Mini CCTV Camera Starlight Waterproof Small Black Metal Bullet Street Large Angle 3.6MM lens Surveillance Camera
Features:
By using the high performance sensor, image is clear, delicate and high performance sensor, image is clear, delicate;
Analog HD AHD-H@AHD video output;
The transmission distance is 500 meters;
Support automatic electronic shutter function, adapt to different monitoring environment;
Million pixel HD video transmission of low cost, long distance, no delay, high efficiency, anti-jamming and easy to implement;
Easy installation & operation, as same as analog CCTV system
More acceptable, lower price than analog surveilance system
NO Delay, Real time Display
Installation Notes:
(1) Do not use this product falls on the ground or by strong percussion;
(2) unless instructed otherwise, do not dismantle the machine;
(3) before use to determine whether the specified power supply voltage;
(4) to avoid targeting light (such as sunlight, lighting, etc.), otherwise easily lead to too bright or pull light phenomena (this is not a failure), will also affect the CCD life;
(5) Avoid wet conditions, dust, extreme heat, extreme cold, strong electromagnetic radiation and other venues;
(Not include OSD Menu and Power Supply ,Suggest Camera Don't use completely dark environment)
important Notes:
1>>This is Full HD AHD 1920P Camera ,Work Must use 1080P Recording Format AHD DVR (AHD-H System or AHDN-1080N System)!! If NO USE 1080P Record AHD DVR, AHD Camera NOT Work .
2>>You Can't use AHD-M SYSTEM 720P Record AHD DVR and Common DVR ,the AHD Camera it NOT Work!!!
3>>Camera Work Can only use 1080P Record AHD DVR!!!
![](https://ae01.alicdn.com/kf/Sb39aebb080314ffd9997485be5da219bI.jpg)
![](https://ae01.alicdn.com/kf/S689cc46fbf344d9f8d3fac3c64fc5890c.jpg)
![](https://ae01.alicdn.com/kf/Sfa1a59ceea4d40939fd63cac49c67f7br.jpg)
![](http://ae01.alicdn.com/kf/HTB1KfjHKXXXXXabXpXXq6xXFXXXO.jpg)
![](https://ae01.alicdn.com/kf/S80ff2221f91b4d1f8bfd06e5c5c1d758g.jpg)
![](https://ae01.alicdn.com/kf/Sd070198ded6d49c5a7eb41870153a44co.jpg)
![](http://ae01.alicdn.com/kf/UT8._5IXmpeXXagOFbX1.jpg)
![](http://ae01.alicdn.com/kf/UT88a1JXcJeXXagOFbXH.jpg)
![](http://ae01.alicdn.com/kf/UT835OJXgXbXXagOFbXh.jpg)
![](http://ae01.alicdn.com/kf/UT8q8WIXeRfXXagOFbXJ.jpg)
![](http://ae01.alicdn.com/kf/UT8s9aIXj0fXXagOFbX3.jpg)
![](http://ae01.alicdn.com/kf/UT8DTmIXc8fXXagOFbXO.jpg)
![](http://ae01.alicdn.com/kf/UT8ryyJXmtbXXagOFbXX.jpg)
![](http://ae01.alicdn.com/kf/UT887KJXcxaXXagOFbXC.jpg)
![](http://ae01.alicdn.com/kf/UT8G_KIXhJeXXagOFbXQ.jpg)
Specification
Main Chip
High performance
Sony processor
Image Sensor
1080P:1/3 Sony IMX323+NVP2441H
3MP:1/3 Sony IMX291+FH8536E ( Starlight )
Effective Pixel
PAL : 1920*1080@25fps
NTSC : 1920*1080@30fps
Signal System PAL/NTSC
Video Standard Follow AHD and CVBS Standard
Video Output 1CH AHD HD/CVBS Standard Singal Output(Switchable)
Max Transmission Distance Common 75-3 Cable can be up to 500m
HD 3MP Lens size 3.6MM
Minimum Illumination 0.0001LUX/F1.2(Led on)
3D Noise Reduction YES
LED NO
Lightning protection YES
Shutter Speed 4/25s-1/45,000s
BLC Off/Low/Medium/High/Highest
White Balance Auto White Balance
HLC Auto
Operation Temperature -45°C~55°C
Power Supply DC12V
Housing Material Metal
IP Grade IP65 indoor
